Introduction
With Microsoft's introduction to Hosted Agents comes a next logical question. How to implement this? Organizations need a method that is quick, repeatable, and requires minimal adjustments to their existing tooling and processes. Thus, we will walk through how to deploy a Hosted Agent through a repeatable GitHub Action.
If this is new to you this blog is a follow up to Deploying Foundry Hosted Agents via REST API | Microsoft Community Hub.
Before You Start
This action assumes the following are already in place in the workflow that calls it:
- An existing Microsoft Foundry project with a deployed model.
- A container image already pushed to Azure Container Registry (ACR).
- An identity with the **Foundry User** role on the Foundry project. See [hosted agent permissions](https://learn.microsoft.com/en-us/azure/foundry/agents/concepts/hosted-agent-permissions) for the full permissions reference.
- A runner with `az`, `jq`, and `python3` installed. This is true on `ubuntu-latest`; if you self-host, install them explicitly.
- azure/login configured in the caller workflow **before** this action runs.
⚠️ *Identity prerequisite This action assumes `azure/login` has already run in the caller workflow and that the resulting identity holds a Foundry data-plane role (e.g., Foundry User). Without that, `az account get-access-token` will fail before the REST call is made.
Requirements
Grounding ourselves in our requirements to implement the deployment processes, in the quickest way that leverages minimal adjustments and a repeatable process, we will leverage GitHub Action and Bash. The Bash script will take a series of arguments that will be used to call the REST API.
The action requires four inputs: `project_endpoint`, `agent_name`, `image`, and `model_deployment_name`. The example pipeline wires these from the outputs of a preceding IaC step, but the action itself takes plain strings. These strings can come from any tool that can hand them off as workflow inputs. This keeps it flexible and limits adjustments to existing CI/CD processes.
If interested, one can use the Azure Developer CLI (`azd up`) command which is documented via Microsoft official examples and MS Learn. This blog chose not to cover this as the majority of enterprise customers already have tooling they are leveraging other than `azd`.
Also, one could use the `azure.ai.projects` library to create an agent. This blog made the decision not to go down this route as not all organizations have adopted the philosophy of allowing application code to create underlying compute infrastructure. Additionally, some organizations desire teams outside of developers to control and set the size of the Micro VM (referred to as the "sandbox" in the Foundry docs) that the Hosted Agent is running on.
If your organization does not use GitHub Actions this step should be duplicatable in Azure DevOps leveraging the Bash task.
Deployment Steps
For us to do this appropriately let's take a step back and evaluate a CI/CD workflow for an Agent whose definition is stored in a container.
Ideally a pipeline should follow steps outlined in CI/CD for AI Agents on Microsoft Foundry. Those pipelines typically take the shape build/push → IaC → update agent → smoke test. For our purposes, since we are hyper-focusing on the Hosted Agent Deployment via REST API we are going to focus on the repeatable GitHub Action of deploying the agent. To emphasize this our workflow will focus on the step called "Update agent — Foundry data plane POST `agents/NAME/versions`".
Based on organization preference, I can understand the need to break out the update agent step into a separate workflow. We traditionally don't recommend this as keeping everything in one pipeline means one set of failures to triage, one history to read, and one CI/CD surface to keep current. but This action though is structured to support a split if your release process requires it.
Hosted Agent REST Deployment Action
This is the crux of why the article exists. If you've followed my style of repeatable DevOps process for YAML Pipelines, this action follows similar principles. We will parametrize with defaults to empower minimal configuration while also optimizing for flexibility. To view the full example check out the Update Foundry Agent action .
The Inputs, Outputs, and `runs:` blocks shown below all live in a single file: `.github/actions/update-agent/action.yml`.
Inputs
Here are those parameters with descriptions and defaults:
inputs: project_endpoint: description: Foundry project endpoint URL required: true agent_name: description: Name of the hosted agent required: true image: description: Full container image reference (registry/name:tag) required: true model_deployment_name: description: Name of the AI model deployment required: true cpu: description: CPU allocation for the agent container required: false default: '0.25' memory: description: Memory allocation for the agent container required: false default: '0.5Gi'Verify the latest sandbox sizes at hosted-agents#sandbox-sizes There is also guidance on right-sizing your Micro VMs. At the time of this writing here are the available combinations:
Outputs
We should output values that make sense for subsequent steps in the workflow. Every instance that calls this action may not use them, but it's always good to expose non-secret values just in case.
In our case we are creating a new version of the agent, so let's output that agent version:
outputs: agent_version: description: Version ID returned by the Foundry data plane value: ${{ steps.post.outputs.agent_version }}`agent_version` is the version identifier returned by the data plane. Capture this in your pipeline (artifact, release tag, etc.) so you have an audit trail and a target to re-deploy against if a future version needs to be rolled back. Subsequent steps in the workflow can reference it via `${{ steps.<step-id>.outputs.agent_version }}`.
Action
The action will need to map our environment variables being passed into the input as the first step. After that we will need to get an access token from Azure so we can then call the REST API endpoint.
Once we have this, we will need to prepare the body of our call. Verify against the API for all valid properties. For our example I chose not to set `rai_config` (Responsible AI overview) and `tools` (function/tool bindings) to keep things simple.
runs: using: composite steps: - name: Post agent version to Foundry data plane id: post shell: bash env: PROJECT_ENDPOINT: ${{ inputs.project_endpoint }} AGENT_NAME: ${{ inputs.agent_name }} IMAGE: ${{ inputs.image }} MODEL_DEPLOYMENT_NAME: ${{ inputs.model_deployment_name }} CPU: ${{ inputs.cpu }} MEMORY: ${{ inputs.memory }} run: | FOUNDRY_TOKEN=$(az account get-access-token \ --resource "https://ai.azure.com/" \ --query accessToken -o tsv) AGENT_REQUEST_BODY=$(jq -n \ --arg cpu "$CPU" \ --arg memory "$MEMORY" \ --arg model "$MODEL_DEPLOYMENT_NAME" \ --arg image "$IMAGE" \ '{ definition: { kind: "hosted", container_protocol_versions: [{protocol: "responses", version: "1.0.0"}], cpu: $cpu, memory: $memory, environment_variables: {AZURE_AI_MODEL_DEPLOYMENT_NAME: $model}, image: $image
⚠️ **Heads up on logs.** The line that echoes `HTTP ${HTTP_STATUS}: $(cat /tmp/agent_response.json)` dumps the full response body to the job log. If your request body contains sensitive `environment_variables`, the API may return them in the response, where they will appear in plain text in the workflow log. Either scrub the response before echoing, or echo only the `version` field on success.
A 2xx response confirms the data plane accepted the new agent version. Confirming the agent behaves as intended is a separate step. This is done typically with a smoke test against the deployed agent in a later workflow job.
If something goes wrong the most common failures are:
- 401/403- `azure/login` didn't run, the identity is missing a Foundry data-plane role, or the wrong subscription is selected. Check the `azure/login` step and confirm the identity holds **Foundry User** (or higher) on the Foundry project (see the *Before You Start* callout above).
- 404 - wrong `project_endpoint`, or the agent named in `agent_name` does not yet exist on the project. The agent must exist before posting a new version.
- 400 - body or model issue: invalid `cpu` / `memory` shape, a required field missing, or `model_deployment_name` pointing at a deployment that isn't reachable from this project.
Calling the Action
So now that we have the action, how can we scale this across multiple workflows? Simple, we just need to pass in the required parameters. Here is an example, with a stubbed `deploy-iac` step so can the outputs passed into the action as inputs:
- name: Deploy Bicep infrastructure id: deploy-iac uses: ./.github/actions/deploy-bicep with: environment_name: ${{ inputs.environment_name || 'main' }} location: ${{ inputs.location || 'swedencentral' }} - name: Update agent uses: ./.github/actions/update-agent with: project_endpoint: ${{ steps.deploy-iac.outputs.project_endpoint }} agent_name: ${{ inputs.agent_name }} image: ${{ steps.deploy-iac.outputs.acr_endpoint }}/${{ inputs.image_name }}:${{ inputs.image_tag }} model_deployment_name: ${{ steps.deploy-iac.outputs.model_deployment_name }}
And just to show we can call the same action multiple times here are two examples that do just that: Deploy (Bicep) and Deploy (Terraform).
Conclusion
The composite action shown above gives organizations what the introduction called for: a quick, repeatable way to deploy a Hosted Agent that requires minimal adjustments to the GitHub Actions tooling and processes already in use. With it wired into a workflow, deploying a new Hosted Agent version becomes a standard step in your pipeline.
