Foundry Toolkit for VS Code at //build: Hosted Agents End-to-End, a Smarter Toolbox, and More by leoyao
Thursday June 4^th, 2026 at 5:43 AM

New blog articles in Microsoft Community Hub

We’re excited to share what’s new for Foundry Toolkit for Visual Studio Code at //build 2026. Since going generally available, the toolkit has kept moving fast, and this release is a big one. The headline: a complete, end-to-end Hosted Agent experience, scaffold, run, deploy, and observe without ever leaving VS Code. On top of that, we’ve expanded the Toolbox with native enterprise integrations and shipped a wave of LangGraph samples so every developer has a clear path from idea to production. From your first prompt to a production-grade, observable agent, Foundry Toolkit meets you where you are.

Hosted Agents, End to End

Building an agent is the easy part; getting it from a first draft to a production-grade, observable service is what matters. This release makes the full Hosted Agent lifecycle available in VS Code, and it follows the way you actually work — scaffold, run, deploy, observe.

Scaffold — start from a rich set of samples

Hosted Agent creation now opens with a refreshed scaffolding experience and a rich sample selection, so you start from a working, framework-appropriate template instead of a blank file. Creation is smarter, too: we auto-select your subscription when there’s only one, gate tabs more clearly, and tightened spacing for a cleaner setup flow.

New Hosted Agent scaffolding dialog with the rich sample picker open

Run (F5) — inspect as you build

Press F5 and your agent runs locally with the Agent Inspector, now aligned with the rest of the extension and featuring Copilot SDK visualization so you can see what the Inspector visualizes as the agent executes. It’s the fastest loop from change to verification before anything leaves your machine.

Deploy — a new UX and new ways to ship

Different teams ship differently, so deployment got a refreshed UX and two new options for Hosted Agents:

ZIP Code Deploy: Package your agent source as a ZIP and deploy it directly to Microsoft Foundry Agent Service.

Bring-Your-Own-Image (BYOI): Already have a pre-built container in your own Azure Container Registry? Deploy straight from it.

Hosted Agent deploy dialog showing "ZIP code deploy" and "Bring-your-own-image (ACR)" side by side.

Observe — know it works in production

Once deployed, the full observability story is now available:

Hosted Agent Tracing: Inspect end-to-end traces of Hosted Agent invocations directly from VS Code — tool calls, delegation chains, and timing for real debugging instead of guesswork.

Continuous Evaluation Settings: A new page to configure ongoing evaluation for deployed Hosted Agents, so quality is measured continuously — not just at ship time.

Evaluations Node: One-click access to evaluation runs and results right from the Foundry project tree.

Hosted Agent trace view showing a span tree of tool calls and timings.

A Smarter, More Connected Toolbox

What it is, and why it matters

A Toolbox is how your agent gets its capabilities — the curated set of tools, knowledge sources, and integrations it can call at runtime. Instead of hand-wiring each connection, you assemble a Toolbox once and your agent consumes it consistently across local runs and production. The result: agents that can act on real enterprise data and systems, with the connections managed in one place.

From what to how: create, connect, consume

Create: Start a new Toolbox from the Foundry Toolkit sidebar “Tools Catalog” and pick the capabilities your agent needs.

Connect: Configure and wire in enterprise systems through native, first-class connections once, and use it for all your agents.

Consume: Reference the Toolbox from your Hosted Agent so its tools are available the moment the agent runs, locally (F5) and once deployed.

New this release

Building on that flow, the Toolbox is now richer and more enterprise-ready:

WorkIQ as a Built-in Tool: A first-class WorkIQ experience powered by A2A connections — no MCP fallback required. End-to-end toolbox creation with WorkIQ works out of the box.

Fabric IQ (OneLake Catalog) Integration: Connect your agents to Microsoft Fabric OneLake catalogs directly from the Toolbox.

Toolbox Guardrails: Apply content-safety guardrails to your Toolbox for safer agent execution.

Faster discovery: A new Toolbox Search Toggle and Agent Tool Multi-Select let you find and wire in multiple tools in a single action.

Redesigned Tools Catalog, including WorkIQ and Fabric IQ tiles.

LangGraph Reaches Parity

LangGraph developers, this one is for you. We’ve added five new Hosted Agent samples that bring LangGraph to full parity with the Agent Framework Responses learning path — so you get an equivalent, end-to-end walkthrough no matter which framework you prefer:

MCP — tool loading from a remote MCP server (defaults to GitHub Copilot MCP) via MultiServerMCPClient.

Workflows — a custom StateGraph chaining three specialized LLM nodes: slogan writer, legal reviewer, and formatter.

Files — local filesystem tools plus the Foundry-Toolbox code_interpreter working over session-uploaded files.

Human-in-the-Loop — a StateGraph that drafts a proposal and pauses for approval via langgraph.types.interrupt.

Observability — GenAI OpenTelemetry tracing with enable_auto_tracing(); spans, metrics, and logs flow to Application Insights.

We’ve also refreshed the existing bring-your-own LangGraph samples against the new hosting layer (chat with local tools, Foundry-managed Toolbox loading, and SSE-streamed multi-turn sessions backed by a MemorySaver checkpointer), so every sample reflects how Hosted Agents work today.

Workflow visualization of the LangGraph human-in-the-loop sample paused at an approval node.

Polish Across the Board

A release is more than headline features. This one also includes a redesigned Prompt Builder “Improve an Instruction” dialog for faster iteration, fixes for MCP toolbox tool icons, clearer ZIP-deploy error surfacing, and assorted Agent Builder and Playground regression fixes — the whole experience feels tighter end to end.

Get Started Today

Install: Foundry Toolkit on the VS Code Marketplace

Quick Start: Follow our getting-started tutorial to build your first Hosted Agent

Deep Dive: Explore the documentation, samples, and LangGraph parity walkthroughs

Join the Community

Share your projects, file issues, or suggest features on our GitHub repository. We can’t wait to see what you build.

Welcome to the next chapter of AI development!

Read the whole story

alvinashcraft

5 hours ago

reply

Pennsylvania, USA

The case for language clarity, with Iva Cheung
Thursday June 4^th, 2026 at 5:43 AM

Grammar Girl: For Writers and Language Lovers.

1191. This week, we talk to Iva Cheung, a plain language expert and editor who has helped shape Canada's accessibility standards. We look at what plain language actually means (it's more than just short words and simple sentences) and why it matters for healthcare, legal rights, and everyday communication. Then we explore cognitive load theory, the expertise reversal effect, and why user testing is the secret ingredient most writers skip.

Find more from Iva at IvaCheung.com.

🔗 Join the Grammar Girl Patreon.

🔗 Share your familect recording in Speakpipe or by leaving a voicemail at 833-214-GIRL (833-214-4475)

🔗 Watch my LinkedIn Learning writing courses.

🔗 Subscribe to the newsletter.

🔗 Take our advertising survey.

🔗 Get the edited transcript here.

🔗 Get Grammar Girl books.

| HOST: Mignon Fogarty

| Grammar Girl is part of the Quick and Dirty Tips podcast network.

Audio Engineer: Dan Feierabend
Director of Podcast: Holly Hutchings
Advertising Operations Specialist: Morgan Christianson
Marketing and Video: Nat Hoopes, Rebekah Sebastian
Podcast Associate: Maram Elnagheeb

| Theme music by Catherine Rannus.

| Grammar Girl Social Media: YouTube. TikTok. Facebook. Threads. Instagram. LinkedIn. Mastodon. Bluesky.

Hosted on Acast. See acast.com/privacy for more information.

Download audio: https://sphinx.acast.com/p/open/s/69c1476c007cdcf83fc0964b/e/6a1a245fdd90858af9382270/media.mp3

Read the whole story

alvinashcraft

5 hours ago

reply

Pennsylvania, USA

Announcing Blazorise 2.2 - Cetina
Thursday June 4^th, 2026 at 5:43 AM

Blazorise Blog

Blazorise 2.2, codenamed Cetina, is named after one of the most powerful rivers in Croatia, originating beneath the highest mountain in Croatia.

Read the whole story

alvinashcraft

5 hours ago

reply

Pennsylvania, USA

GitHub Copilot Multi-Repo Instructions: Sharing Skills, Agents, and Conventions Across Repos by Chris Bradshaw
Thursday June 4^th, 2026 at 5:42 AM

Arinco

TL;DR: GitHub Copilot writes idiomatic code, but doesn’t know your team’s conventions, pitfalls, or cross-repo workflows. At Arinco, we addressed this using GitHub Copilot multi-repo instructions — a logical structure of markdown files (per-repo instructions, a shared Copilot repo, skills, and agents) committed to source control, so both Copilot and developers know exactly where conventions, procedures, and guardrails live. The result: Copilot Agents match what a senior team member would plan, write and test, along with quality-of-life skills like raising a PR is now a single command (diff analysis, readiness checks, work item links, creation in Azure DevOps, all automated).

The Problem: Copilot Doesn’t Know Your Conventions

Out of the box, Copilot is trained on public code, for someone elses project. It’ll generate perfectly adequate C#, but it doesn’t know that your team uses primary constructors, that your handlers follow a two-phase validate-then-write flow, or that injecting a shared DbContext into parallel code will blow up at runtime.

That problem compounds across multiple repositories. When your platform spans 15+ repos (shared contracts, pipeline templates, database schemas that need to stay in sync) conventions drift fast. One repo uses file-scoped namespaces, another doesn’t. Pipeline YAML gets copy-pasted with subtle mutations. The wiki that’s supposed to keep things aligned hasn’t been updated in six months.

“How do you give Copilot enough context about your specific platform that its suggestions actually match what a senior team member would write?”

The answer turned out to be surprisingly simple: tell it. In writing. In the repo.

The Solution

What we wanted was a way to define conventions once, share them across every repo, and have them actively enforced through the tooling developers already use. The answer at Arinco was a set of GitHub Copilot multi-repo instructions – shared markdown files, committed to source control, applied consistently across every repository through a multi-root VS Code workspace.

Solution Level 1: Per-Repo Copilot Instructions

VS Code’s Copilot extension looks for a .github/copilot-instructions.md file in each repository. Whatever you put in there becomes part of the context Copilot uses when generating suggestions, answering questions, or writing code in that repo.

We started small. Just the basics:


					## Build and Test

dotnet build
dotnet test
dotnet test --filter "FullyQualifiedName~MyTestName"

## C# Conventions

- PascalCase for public members, _camelCase for private fields
- Async methods end with `Async` and accept `CancellationToken`
- Use primary constructors for services and repositories
- Repository pattern is deferred-save: stage changes, commit once
Even this much made an immediate difference. Copilot stopped suggesting Task.Run for async operations. It started using CancellationToken in method signatures without being asked. It used _camelCase for private fields instead of whatever the training data preferred that day.
But real value came when we started adding things that aren’t obvious. The pitfalls:
## Pitfalls

- Never inject a shared DbContext into parallel fan-out code.
  Use IDbContextFactory and create a context per-operation.
  A shared context throws "A second operation was started on this
  context instance" as soon as two tasks overlap.

- NuGet package versions for message contracts must match across
  producer and consumer repos. Version skew causes silent
  deserialization failures that surface as dead-letter messages
  days later.

## Anti-Patterns (NEVER DO THESE)

1. Do not use lock tokens for message deletion, use MessageId
2. Do not call OperationResult.Failure() without passing the exception
3. Do not put @code blocks in .razor files, use .razor.cs code-behind

That pitfalls section has probably prevented more bugs than any linter we could have configured. When someone asks Copilot “help me process these schools in parallel,” it now knows to suggest IDbContextFactory instead of injecting the context directly. Because we told it what happens when you don’t.

Per-repo instructions solve the single-repo problem. The next question is how to make Copilot see every repo on the platform at once.

Solution Level 2: The Multi-Root Workspace

This is the bit that ties everything together, and it’s easy to overlook because it’s just a JSON file. But without it, nothing else in this post works.

VS Code supports multi-root workspaces. A single window that opens multiple repository folders side by side. We maintain a .code-workspace file that includes every repo on the platform:


					{
  "folders": [
    { "name": "Copilot Shared", "path": "../Copilot.Shared" },
    { "path": "../Integration.Core" },
    { "path": "../Integration.Templates" },
    { "path": "../Integration.Engine" },
    { "path": "../Integration.Acquisition" },
    { "path": "../Integration.MessageContracts" },
    { "path": "../Integration.Dashboard" },
    { "path": "../Integration.LearningSystems" }
  ]
}

This gives you three things for free:

Cross-repo search: Ctrl+Shift+F finds all usages of a message type across producers and consumers without switching windows
Copilot has full visibility: it can see the contracts repo, the consumer, the producer, and the database schema all at once when answering questions
The shared Copilot repo is automatically discovered: because it’s a folder in the workspace, VS Code picks up its.github/copilot-instructions.md and applies it as workspace-level context

That third point is the missing ingredient. The shared Copilot repo only works because it’s open in the workspace. If you clone it but don’t include it in your workspace file, Copilot never sees it. The workspace file is what makes the inheritance hierarchy real.

We keep the workspace file in the shared repo itself and treat it as a first-class artefact. When a new integration repo is added to the platform, the workspace file gets updated in the same PR. New team members clone everything, open the workspace file, and they’re immediately working with full platform context. Both for themselves and for Copilot.

The workspace gives Copilot access to every repo. What it still doesn’t have is a place for conventions that belong to no single repo, but to all of them.

Solution Level 3: A Shared Repo for Multi-Repo Copilot Instructions

Why a Dedicated Repo

Per-repo instructions handle component-specific conventions well, but we had a problem: conventions that span the entire platform. Git workflow. Security requirements. Environment promotion order. The architectural data flows across repos. These don’t belong in any single repo. They belong everywhere.

The approach we took was to create a dedicated repository that contains nothing but Copilot customisation files. No application code. No infrastructure. Just context for the AI.

Repository Structure


					Copilot.Shared/
├── .github/
│   ├── copilot-instructions.md
│   ├── agents/
│   │   ├── dead-letter-investigator.agent.md
│   │   ├── pr-evaluator.agent.md
│   │   └── architecture-review.agent.md
│   ├── skills/
│   │   ├── field-mapping-change/
│   │   │   └── SKILL.md
│   │   ├── service-bus-contract-change/
│   │   │   └── SKILL.md
│   │   └── pipeline-template-upgrade/
│   │       └── SKILL.md
│   ├── instructions/
│   │   ├── branch-targeting.instructions.md
│   │   └── multi-repo-freshness.instructions.md
│   ├── prompts/
│   │   ├── release-checklist.prompt.md
│   │   └── hotfix-checklist.prompt.md
│   └── hooks/
│       ├── team-guardrails.json
│       └── scripts/
└── README.md

This repo is added as a folder in a VS Code multi-root workspace alongside all the integration repos. Because Copilot discovers.github/copilot-instructions.md automatically, the shared instructions apply across the entire workspace without any configuration.

The Shared Instructions File as a Routing Table

The shared copilot-instructions.md acts as a routing table. It describes the overall architecture, lists every available skill and agent, defines cross-project conventions, and links out to each repo’s own instructions for component-specific rules:


					## Architecture

Source API → Azure Functions (Acquisition)
  → Service Bus (contracts in MessageContracts repo)
  → Azure Functions (Engine)
  → SQL Database (Common Data Model)
  ← Read API (per-domain Function App + APIM policy)
  ← Consumers via APIM

## Conventions

- Use Managed Identity and Entra ID auth, no secrets in source
- Secrets in Key Vault, non-secret config in App Configuration
- Async I/O methods end with `Async` and take `CancellationToken`
- Service Bus processing uses explicit dead-letter for data errors
  and retry for transient failures
- Structured logging with named parameters and correlation scope

## Available Skills

| Task                                    | Skill                      |
|-----------------------------------------|----------------------------|
| Add a field end-to-end (API → DB)       | field-mapping-change       |
| Modify a Service Bus message contract   | service-bus-contract-change|
| Bump pipeline template version          | pipeline-template-upgrade  |
| Implement a new handler end-to-end      | engine-new-handler         |

Inheritance: Workspace Defaults Plus Per-Repo Overrides

This creates an inheritance hierarchy: workspace-level defaults from the shared repo, overridden or extended by per-repo instructions. Same concept as .editorconfig inheritance but for AI-assisted development.

Shared instructions are great for what the platform looks like, but they don’t capture how to make changes that ripple through it. That’s where skills come in.

Solution Level 4: Skills (Procedural Knowledge)

Static instructions tell Copilot how to write code. Skills tell it what to do for specific multi-step tasks. The kind of cross-cutting changes that normally require tribal knowledge.

What a Skill Looks Like

A skill is a SKILL.md file with YAML frontmatter that describes when to use it, and a step-by-step procedure covering which repos to touch, in what order, and what can go wrong:


					---
name: field-mapping-change
description: "Add or modify a field flowing from the source API through
  Service Bus to the Common Data Model database. Crosses 3 repos in strict order."
argument-hint: "Describe the field name, source, target column, and
  which entity types it applies to"
---
The frontmatter is the part Copilot reads to decide whether to load the skill. The procedure body is what it follows once it does.
Example: A Field Mapping Change Across Three Repos
# Field Mapping Change

## When To Use
- Adding a new field from the source API to the database
- Renaming or correcting an existing mapped attribute
- Any change that touches the DTO → message → mapper → SQL chain

## Full Change Chain

A complete field mapping change crosses three repos in a specific
order. Always publish the contract change first, then update the
consumer (Engine) before the producer (Acquisition).

## Procedure

### Step 1 - Update the message contract (MessageContracts repo)
1. Add the property to the relevant DTO
2. Bump the NuGet package version
3. Publish the package

### Step 2 - Update the database schema (Data model repo)
1. Add the column to the relevant table
2. Rebuild the DACPAC
3. Check if managed identity permissions need updating

### Step 3 - Update the processing engine (Engine repo)
1. Bump the MessageContracts NuGet version
2. Add the field to the mapper
3. Update unit tests

### Step 4 - Update the acquisition layer (Acquisition repo)
1. Bump the MessageContracts NuGet version
2. Populate the new field from the API response
3. Update unit tests

### Step 5 - Cross-repo validation
1. Verify NuGet versions match across all consuming repos
2. Run tests in each repo
3. Confirm the field flows end-to-end

## Common Mistakes

- Adding the SQL column but not the mapper → field is always null
- Bumping the contract in Engine but not Acquisition → version skew
- Forgetting managed identity SQL permissions on the new column

Why the Ordering Matters

The value here isn’t the individual steps. Any senior developer could figure those out. The value is the ordering constraints. “MessageContracts first, then Engine, then Acquisition” isn’t intuitive to someone new, but getting it wrong means messages silently fail deserialization and pile up in the dead-letter queue for days before anyone notices.

We have thirteen skills covering everything from schema changes to pipeline template upgrades. When someone asks Copilot to help with a task that matches a skill, it loads the procedure and follows it rather than improvising.

Skills cover predictable, procedural work. Agents take this further into investigative and operational territory: judgement calls, tool use, and live system access.

Solution Level 5: Agents (Specialist Personas)

Skills handle procedural work. Agents handle investigative and operational tasks that require judgement, tool access, and domain expertise.

What an Agent Looks Like

An agent is defined in a .agent.md file with YAML frontmatter specifying its name, description, tools, and optionally a preferred model:


					---
name: "Dead Letter Investigator"
description: "Triage Service Bus dead letter queue messages.
  Classify failures and recommend resolution paths."
tools: [read, search, execute]
model: "GPT-4o (copilot)"
---
You are a Service Bus dead letter queue specialist. Your job is to
triage dead-lettered messages and determine the correct resolution
path without writing any code.

We built seven agents. Two of them turned out to be genuine quality-of-life wins that the team actually talks about.

Dead Letter Queue Triage

Before the agent, triaging a dead-letter message was a 20-30 minute exercise: peek the message in a terminal, read the JSON body, figure out which handler threw, check deployment history, maybe grep App Insights, and eventually decide whether to resubmit. Nobody enjoyed it.

The agent classifies every message into one of three categories:

Class	Type	Resolution
A – Data error	Bad source data, no code fix needed	Don’t resubmit. Escalate to data team.
B – Transient infra error	Timeout, connection failure, lock expiry	Resubmit and monitor.
C – Code/config bug	Fix required before resubmit	Deploy the fix first. Resubmit only the latest message per entity, purge duplicates.

The categories matter more than they look. Each one maps to a different action, and the wrong action (resubmitting a poison message, or escalating a transient blip) creates more work, not less.

The agent can peek messages live from the DLQ without consuming them, check NuGet package versions across repos (version skew is the number one cause of deserialization dead-letters), cross-reference recent deployments, and produce a verdict.

The real value is the production-hardened gotchas baked into its instructions. Things we learned from actual incidents. Like: when a code bug causes duplicate messages to accumulate over days (same entity, resubmitted hourly), you keep only the latest per entity and purge the rest rather than resubmitting hundreds of duplicates and overwhelming the handler.

What used to be 20 minutes of context-switching is now a 30-second conversation.

PR Creation End-to-End

The second agent automates the PR workflow in three phases:

Phase 1: reads the git diff, identifies what changed, extracts the work item ID from the branch name, and generates a structured PR description.

Phase 2: validates readiness. Correct branch target, NuGet versions aligned, builds pass, no secrets in the diff, pipeline template tag is current. Pass/fail verdict with specific blockers.

Phase 3: if the user requests it, actually creates the PR in Azure DevOps using MCP (Model Context Protocol) server tools. Resolves the repository GUID, constructs the PR with the generated description, links work items, and returns the URL.

One implementation detail worth calling out: the Azure DevOps MCP tool silently fails if you pass a repository name instead of a GUID. So, the agent always resolves the GUID first by listing repos and filtering. That kind of gotcha is exactly what belongs encoded in an agent rather than in someone’s memory.

What used to be: write a description → manually check versions → open the browser → create the PR → link the work item, is now: “raise a PR for this branch” → done.

The Inheritance Hierarchy

Putting it all together, the context hierarchy looks like this:


					Copilot.Shared/.github/copilot-instructions.md     ← platform-wide defaults
  ├── instructions/*.instructions.md                ← contextual guardrails
  ├── skills/*/SKILL.md                             ← procedural checklists (loaded on demand)
  ├── agents/*.agent.md                             ← specialist personas
  ├── prompts/*.prompt.md                           ← reusable one-off templates
  └── hooks/                                        ← automated interception

Repo-A/.github/copilot-instructions.md              ← repo-specific overrides
Repo-B/.github/copilot-instructions.md              ← repo-specific overrides

Workspace-level defaults apply everywhere. Repo-level instructions override or extend for their specific context. Skills and agents are loaded on demand when the task matches. Hooks intercept in real-time.

How We Maintain It

The most common question: “doesn’t this go stale?”

We treat customisation files like code. If you change a convention (say, you switch from Allman braces to file-scoped namespaces) you update the instruction in the same PR. If an agent’s classification rules miss a new failure mode, you add it when you discover it.

Because it’s all in a git repo, it goes through the normal PR workflow. Changes are reviewable, attributable, and reversible. When someone improves a skill or adds a production gotcha to an agent, everyone gets it on their next git pull.

The shared repo also acts as onboarding documentation by accident. New team members read the skills to understand cross-repo change procedures. They read the agents to understand operational workflows. They read the instructions to understand conventions. None of it was written as documentation – it was written for Copilot – but it turns out that context useful for an AI is also context useful for a human.

The Honest Tradeoffs

It’s not magic. Copilot still gets things wrong. But it gets things wrong in the direction of your conventions rather than the direction of random Stack Overflow answers.
Maintenance is real. Someone has to update the files when patterns change. We’ve found it’s less effort than maintaining a wiki because the feedback loop is tighter: wrong instruction → wrong suggestion → fix the instruction.
Model limits apply. Very large instruction files can exceed context limits. Keep them focused. The shared file is a routing table, not an encyclopedia.
Skills don’t replace judgement. They encode the mechanical steps. The “should we do this at all?” question still needs a human.

Closing Thought

The thing that surprised us most was how small the investment was relative to the payoff. The shared repo is about 20 markdown files. Each repo’s instruction file is a page or two. The agents are a couple of pages each. Total effort to set up: a few days. Total effort to maintain: a few minutes per PR when conventions change.

The quality-of-life agents (DLQ triage and PR creation) turned out to be the things the team actually talks about. Not because they’re technically impressive, but because they removed the tasks that were just annoying enough to dread but not important enough to properly automate with traditional tooling. Copilot agents sit in a sweet spot: cheaper to build than an internal tool, easier to maintain than a runbook, and they get better as you encode more production lessons into them.

If you’re using Copilot but haven’t written a copilot-instructions.md yet, start there. Tell it your conventions. Tell it your pitfalls. Tell it the things that would take a new team member a month to learn. You’ll be surprised how much better the suggestions get when the AI actually knows how your team writes code. If you want advice or support, contact us.

Read the whole story

alvinashcraft

5 hours ago

reply

Pennsylvania, USA

Rotation revisited: A shocking discovery about gcc’s unidirectional rotation algorithm by Raymond Chen
Thursday June 4^th, 2026 at 5:42 AM

The Old New Thing

Last time, we looked at the rotation algorithm used by gcc libstdc++ for random-access iterators, and I concluded by noting that we’re going to make a shocking discovery.

As with all shocking discoveries, this one will shock disappoint you.

The discovery is that the gcc libstdc++ algorithm is the same as the forward-iterator algorithm!

Let’s run both algorithms on a problem where the two blocks are A1, A2, A3, B1, B2, B3, B4, B5. I’ll put the old forward iterator algorithm on top and the new gcc libstdc++ algorithm below.

first			mid					last
↓			↓					↓
A1	A2	A3	B1	B2	B3	B4	B5
↑			↑					↑
first			mid					last

We swap at first and mid, then advance both pointers. The two algorithms agree until first reaches the end of the original A block.

			first			mid		last
			↓			↓		↓
B1	B2	B3	A1	A2	A3	B4	B5
			↑			↑		↑
			first			mid		last

The old algorithm recurses in order to exchange A1, A2, A3 with B4, B4. This happens by exchanging A1 with B4 and A2 with B5.

The new algorithm just keeps swapping first with mid, which also exchanges A1 with B4 and A2 with B5.

					first			mid last
					↓			↓
B1	B2	B3	B4	B5	A3	A1	A2
					↑			↑
					first			last mid

The old algorithm now recurses to swap the A3 block with the A1+A2 block. And that’s what the new algorithm does, too.

So it’s the same algorithm, just with a different point of view. It’s another case of the geeky thrill of discovering that two things are really the same thing, just with different labels.

Now, the two algorithms are not identical. The new algorithm is symmetric and performs its swaps from right to left if the larger block is on the right. The old algorithm always operates from left to right.

But the similarity is striking.

Next time, we’ll look at how clang performs rotation by decomposing into cycles.

The post Rotation revisited: A shocking discovery about gcc’s unidirectional rotation algorithm appeared first on The Old New Thing.

Read the whole story

alvinashcraft

5 hours ago

reply

Pennsylvania, USA

Paint.NET 5.2 Alpha (build 9650) by Rick Brewster
Wednesday June 3^rd, 2026 at 10:39 PM

Paint.NET Blog

This is an updated alpha build for 5.2 that fixes some more bugs and crashes.

You can read more about 5.2 and what it includes by reading the release notes for the first alpha.

Change Log

Changes since 5.2 Alpha (build 9641):

Fixed an issue when drawing at the edge of the canvas viewport that would cause it to freeze and then jump all the way to the far edge of the canvas
Fixed an issue when drawing a selection using the intersect combine mode that would make the selection disappear and cause other weird issues with history (undo/redo).
Fixed the Move Selected Pixels tool setting color values to 0 for transparent pixels when not necessary (just moving without scaling/rotation, nearest neighbor sampling, etc.). Bug was reported here by @frio.
Fixed clipboard images accessed by plugins not always having a non-null ColorContext property. This property can still be null in some cases (e.g. alpha-only pixel formats). Reported here by @_koh_.
Optimized the compositing code for the Move Selected Pixels tool. The improvement is most noticeable on CPUs with AVX2 (not AVX512) which are not already bottlenecked by the GPU’s rendering.
Fixed a rare crash that could happen while switching tools while also changing the color

Download and Install

This build is available via the built-in updater as long as you have opted-in to pre-release updates. From within Settings -> Updates, enable “Also check for pre-release (beta) versions of paint.net” and then click on the Check Now button. You can also use the links below to download an offline installer or portable ZIP.

You can also download the installer here (for any supported CPU and OS), which is also where you can find downloads for offline installers, portable ZIPs, and deployable MSIs.

Read the whole story

alvinashcraft

12 hours ago

reply

Pennsylvania, USA

Foundry Toolkit for VS Code at //build: Hosted Agents End-to-End, a Smarter Toolbox, and More by leoyao Thursday June 4th, 2026 at 5:43 AM

Hosted Agents, End to End

Scaffold — start from a rich set of samples

A Smarter, More Connected Toolbox

What it is, and why it matters

From what to how: create, connect, consume

New this release

LangGraph Reaches Parity

Polish Across the Board

Get Started Today

Join the Community

The case for language clarity, with Iva Cheung Thursday June 4th, 2026 at 5:43 AM

Announcing Blazorise 2.2 - Cetina Thursday June 4th, 2026 at 5:43 AM

GitHub Copilot Multi-Repo Instructions: Sharing Skills, Agents, and Conventions Across Repos by Chris Bradshaw Thursday June 4th, 2026 at 5:42 AM

Table of Contents

The Solution

Solution Level 1: Per-Repo Copilot Instructions

Solution Level 2: The Multi-Root Workspace

Solution Level 3: A Shared Repo for Multi-Repo Copilot Instructions

Why a Dedicated Repo

Repository Structure

The Shared Instructions File as a Routing Table

Inheritance: Workspace Defaults Plus Per-Repo Overrides

Solution Level 4: Skills (Procedural Knowledge)

What a Skill Looks Like

Why the Ordering Matters

Solution Level 5: Agents (Specialist Personas)

What an Agent Looks Like

Dead Letter Queue Triage

PR Creation End-to-End

The Inheritance Hierarchy

How We Maintain It

The Honest Tradeoffs

Closing Thought

Rotation revisited: A shocking discovery about gcc’s unidirectional rotation algorithm by Raymond Chen Thursday June 4th, 2026 at 5:42 AM

Paint.NET 5.2 Alpha (build 9650) by Rick Brewster Wednesday June 3rd, 2026 at 10:39 PM

Foundry Toolkit for VS Code at //build: Hosted Agents End-to-End, a Smarter Toolbox, and More by leoyao
Thursday June 4^th, 2026 at 5:43 AM

The case for language clarity, with Iva Cheung
Thursday June 4^th, 2026 at 5:43 AM

Announcing Blazorise 2.2 - Cetina
Thursday June 4^th, 2026 at 5:43 AM

GitHub Copilot Multi-Repo Instructions: Sharing Skills, Agents, and Conventions Across Repos by Chris Bradshaw
Thursday June 4^th, 2026 at 5:42 AM

Rotation revisited: A shocking discovery about gcc’s unidirectional rotation algorithm by Raymond Chen
Thursday June 4^th, 2026 at 5:42 AM

Paint.NET 5.2 Alpha (build 9650) by Rick Brewster
Wednesday June 3^rd, 2026 at 10:39 PM
