This is a blog that I am writing for future me and hopefully it’ll help a few of you save some time too! It’s not often that I get to build out a data warehouse from scratch, but when I do, I want to make sure I do it well with best practices in place. Because this is not something I do a lot of, I frequently forget lessons I’ve learned and have to go back and drop tables to recreate them in the best way before it’s too late. One table type that is vital to do right the first time is a Slowly Changing Dimension Type 2 (SCD2 for short).
A SCD2 is a dimension, or lookup, table that soft deletes old records instead of overwriting, modifying, or fully removing records that no longer exist. They can be useful for a number of circumstances, but the primary reason is for time traveling. For example, let’s say that my sales data contains a customer key, but I want to know where a customer lived when they bought the item, not where they live now. In that case, I would need a record in my customer table that contains both their current and past addresses. The example below is for GL accounts, but it can be used with anything.
Skip to the end of this blog for the full script including the table creation.
In the example below, I am tracking any changes to the descriptions of a given account. For example, if GL code 40 changes from INVENTORY to GYM INVENTORY on 6/10/2026 12:00 PM, then any records before that minute in time will return INVENTORY as the GL code description while everything on or after will return GYM INVENTORY.
There are a couple of columns you need to do a proper SCD2 – effective start date, effective end date, hash key, and hash diff. You can have different flavors of names than what I’ve chosen (and some folks don’t leverage a hash key), but the pattern should remain. Effective start and end dates don’t need to include time if you are only loading data on a daily basis. Some folks prefer not to hash keys, but I will warn you that those patterns are not SARGable and may result in very slow inserts if you have a bunch of columns. Instead, hash keys give you an easy way to uniquely identify a unique row that may not have a unique id. Without a hash key, you’ll have to write out long SQL scripts to see if any values in any column match between source and target tables. With hash keys, it’s a simple = or <> to manage.
The downside to using a hash key is that if a column is added, you’ll need to manually rerun all the hashes to include the new column so you don’t end up with a huge change on the day the new column was added. Small price to pay for the daily speed in my opinion, but it could be a valid concern if columns change frequently enough.
Creating the SCD2 Table
One caveat to the data types in the create table, you may notice I’m using DATETIME2(7) instead of just DATETIME. The reason is that I’ve been working in Microsoft Fabric data warehouses for a while and DATETIME is not supported (Data Types in Fabric Data Warehouse – Microsoft Fabric | Microsoft Learn). If you’re using an on-prem SQL Server, feel free to use your preferred datetime data type.
Why the || between each field? The || is a character combo that doesn’t appear in the wild very often and it’s critical to have a clear separation between fields so the hash is truly unique. It’s a small thing that makes a huge difference to make sure you don’t end up modifying records unintentionally.
I’ve also created all the columns to be in alphabetical order for future user sanity with the standard fields at the end (effective start/end and the hashes). There’s also an index on this table for the current records since I’m anticipating most queries will only care about the current account descriptions.
Why two hash columns? The first hash gives us what I think of as Type 1 fields, that is fields that if they change actually denote a new record entirely, not a modification on existing record. The hash diff is built off Type 2 fields, fields that when they change I want the old version soft deleted and the new one set to current.
ONLY DO THIS ONCE. If you drop the table after facts have started flowing in, be aware that it will be very hard to rebuild since you will have deleted the ids that the fact table is trying to join to. If you need to make adjustments to this dimension, put it in a temp table and temporarily suspend the identity insert so you can preserve the original ids of the table.
DROP TABLE IF EXISTS dim.Account;CREATE TABLE dim.Account ( id INT IDENTITY(1,1) NOT NULL ,[4444] VARCHAR(10) NULL ,[4444_desc] VARCHAR(550) NULL ,aa VARCHAR(10) NULL ,aa_desc VARCHAR(550) NULL ,fund VARCHAR(10) NULL ,gl VARCHAR(10) NULL ,gl_desc VARCHAR(550) NULL ,llll VARCHAR(10) NULL ,llll_desc VARCHAR(550) NULL ,o VARCHAR(10) NULL ,obbb VARCHAR(10) NULL ,obbb_desc VARCHAR(550) NULL ,pp VARCHAR(10) NULL ,ppss VARCHAR(10) NULL ,pprr_desc VARCHAR(550) NULL ,s VARCHAR(10) NULL ,s_desc VARCHAR(550) NULL ,effective_start_datetime DATETIME2(7) NOT NULL ,effective_end_datetime DATETIME2(7) NOT NULL ,is_current BIT NOT NULL -- identity hash: the 10 business key columns ,hash_key AS CONVERT(VARBINARY(32), HASHBYTES('SHA2_256', CONCAT( ISNULL([4444], ''), '||' ,ISNULL(aa, ''), '||' ,ISNULL(fund, ''), '||' ,ISNULL(gl, ''), '||' ,ISNULL(llll, ''), '||' ,ISNULL(o, ''), '||' ,ISNULL(obbb, ''), '||' ,ISNULL(pp, ''), '||' ,ISNULL(ppss, ''), '||' ,ISNULL(s, '')))) PERSISTED -- change hash: the 7 tracked description columns ,hash_diff AS CONVERT(VARBINARY(32), HASHBYTES('SHA2_256', CONCAT( ISNULL([4444_desc], ''), '||' ,ISNULL(aa_desc, ''), '||' ,ISNULL(gl_desc, ''), '||' ,ISNULL(llll_desc, ''), '||' ,ISNULL(obbb_desc, ''), '||' ,ISNULL(pprr_desc, ''), '||' ,ISNULL(s_desc, '')))) PERSISTED);-- One current row per identity. Also fails the load loudly if the-- source ever produces two current versions of the same key.-- INCLUDE (hash_diff) covers the Step 3 existence check.CREATE UNIQUE INDEX UX_Account_current ON dim.Account (hash_key) INCLUDE (hash_diff) WHERE is_current = 1;
Create Default “NULL” Row
This is optional, but highly encouraged. Having a NULL row allows your fact table to never have a NULL value in the surrogate key for dim account. Pretty handy for reporting purposes to have a default “Unknown Account” show up instead of an empty record or, heaven forbid, the record get removed automatically when you group on a field from the account dimension. This only needs to be done once and is not included in the stored proc because it never needs to be updated.
SET IDENTITY_INSERT dim.Account ON;INSERT INTO dim.Account ( id ,[4444] ,[4444_desc] ,aa ,aa_desc ,fund ,gl ,gl_desc ,llll ,llll_desc ,o ,obbb ,obbb_desc ,pp ,ppss ,pprr_desc ,s ,s_desc ,effective_start_datetime ,effective_end_datetime ,is_current)VALUES ( -1 ,'Unknown' --you can be more descriptive with these unknowns if you want ,'Unknown' ,'Unknown' ,'Unknown' ,'Unknown' ,'Unknown' ,'Unknown' ,'Unknown' ,'Unknown' ,'Unknown' ,'Unknown' ,'Unknown' ,'Unknown' ,'Unknown' ,'Unknown' ,'Unknown' ,'Unknown' ,'1900-01-01' ,'9999-12-31 23:59:59.9999999' ,1);SET IDENTITY_INSERT dim.Account OFF;
Create Loading Stored Procedure
This is where the real work happens. Keep in mind, this stored procedure will need to be called at some point by an orchestrator. Orchestrators can be a data pipeline, a SQL trigger, a SQL agent job, a notebook, etc. Anything that can call EXEC dim.usp_LoadAccount will work. Be sure that this comes BEFORE you create your fact tables. Fact tables will need to know what id to write into the surrogate key for your dimension.
This stored procedure does a few things – creates the source table, expires (aka soft deletes) records changed in the source, insert new and updated records, and expire the records that don’t exist at all in source anymore.
General notes about this stored procedure:
- The source temporary table does contain an index on it in the example below since that source temp table is called 3 times throughout the procedure.
- Everything is wrapped in transactions and try catches so nothing fails silently, and clear failure messages will bubble up to our orchestrator.
CREATE OR ALTER PROCEDURE dim.usp_Load_AccountASBEGIN SET NOCOUNT ON; SET XACT_ABORT ON; DECLARE @now DATETIME2(7) = SYSDATETIME(); DECLARE @end DATETIME2(7) = DATEADD(MINUTE, -1, @now); -- expired rows end 1 min before successor starts DECLARE @future DATETIME2(7) = '9999-12-31 23:59:59.9999999';/*------------------------------------------------------------Step 1. Stage distinct source rows (outside the transaction to keep the write transaction short). COLLATE DATABASE_DEFAULT normalizes lakehouse collation, so the hashes computed here are byte comparable with dim.Account's persisted hashes.------------------------------------------------------------*/ DROP TABLE IF EXISTS #src; ;WITH src_cast AS ( SELECT DISTINCT CAST([4444] AS VARCHAR(10)) COLLATE DATABASE_DEFAULT AS [4444] ,CAST([4444 Desc] AS VARCHAR(550)) COLLATE DATABASE_DEFAULT AS [4444_desc] ,CAST([AA] AS VARCHAR(10)) COLLATE DATABASE_DEFAULT AS aa ,CAST([AA Desc] AS VARCHAR(550)) COLLATE DATABASE_DEFAULT AS aa_desc ,CAST([Fund] AS VARCHAR(10)) COLLATE DATABASE_DEFAULT AS fund ,CAST([GL] AS VARCHAR(10)) COLLATE DATABASE_DEFAULT AS gl ,CAST([GL Desc] AS VARCHAR(550)) COLLATE DATABASE_DEFAULT AS gl_desc ,CAST([LLLL] AS VARCHAR(10)) COLLATE DATABASE_DEFAULT AS llll ,CAST([LLLL Desc] AS VARCHAR(550)) COLLATE DATABASE_DEFAULT AS llll_desc ,CAST([O] AS VARCHAR(10)) COLLATE DATABASE_DEFAULT AS o ,CAST([OBBB] AS VARCHAR(10)) COLLATE DATABASE_DEFAULT AS obbb ,CAST([OBBB Desc] AS VARCHAR(550)) COLLATE DATABASE_DEFAULT AS obbb_desc ,CAST([PP] AS VARCHAR(10)) COLLATE DATABASE_DEFAULT AS pp ,CAST([PPSS] AS VARCHAR(10)) COLLATE DATABASE_DEFAULT AS ppss ,CAST([PPRR Desc] AS VARCHAR(550)) COLLATE DATABASE_DEFAULT AS pprr_desc ,CAST([S] AS VARCHAR(10)) COLLATE DATABASE_DEFAULT AS s ,CAST([S Desc] AS VARCHAR(550)) COLLATE DATABASE_DEFAULT AS s_desc FROM LakehouseName.dbo.[RawTable] ) SELECT [4444] ,[4444_desc] ,aa ,aa_desc ,fund ,gl ,gl_desc ,llll ,llll_desc ,o ,obbb ,obbb_desc ,pp ,ppss ,pprr_desc ,s ,s_desc -- expressions MUST match dim.Account's computed columns exactly ,CONVERT(VARBINARY(32), HASHBYTES('SHA2_256', CONCAT( ISNULL([4444], ''), '||' ,ISNULL(aa, ''), '||' ,ISNULL(fund, ''), '||' ,ISNULL(gl, ''), '||' ,ISNULL(llll, ''), '||' ,ISNULL(o, ''), '||' ,ISNULL(obbb, ''), '||' ,ISNULL(pp, ''), '||' ,ISNULL(ppss, ''), '||' ,ISNULL(s, '')))) AS hash_key ,CONVERT(VARBINARY(32), HASHBYTES('SHA2_256', CONCAT( ISNULL([4444_desc], ''), '||' ,ISNULL(aa_desc, ''), '||' ,ISNULL(gl_desc, ''), '||' ,ISNULL(llll_desc, ''), '||' ,ISNULL(obbb_desc, ''), '||' ,ISNULL(pprr_desc, ''), '||' ,ISNULL(s_desc, '')))) AS hash_diff INTO #src FROM src_cast; -- index the staged rows: read 3 times on hash_key below CREATE CLUSTERED INDEX CIX_src ON #src (hash_key);/*------------------------------------------------------------Steps 2 to 4 mutate the dimension. Run them atomically so a failure can never leave a key with zero current rows.------------------------------------------------------------*/ BEGIN TRY BEGIN TRANSACTION; /*-------------------------------------------------------- Step 2. Expire current rows whose identity still exists in the source but whose description set changed. --------------------------------------------------------*/ UPDATE d SET effective_end_datetime = @end ,is_current = 0 FROM dim.Account d INNER JOIN #src s ON s.hash_key = d.hash_key WHERE d.is_current = 1 AND d.id <> -1 AND s.hash_diff <> d.hash_diff; /*-------------------------------------------------------- Step 3. Insert brand new identities and new versions of the rows just expired in Step 2. A current row matching on both hashes is unchanged and skipped. --------------------------------------------------------*/ INSERT INTO dim.Account ( [4444] ,[4444_desc] ,aa ,aa_desc ,fund ,gl ,gl_desc ,llll ,llll_desc ,o ,obbb ,obbb_desc ,pp ,ppss ,pprr_desc ,s ,s_desc ,effective_start_datetime ,effective_end_datetime ,is_current ) SELECT s.[4444] ,s.[4444_desc] ,s.aa ,s.aa_desc ,s.fund ,s.gl ,s.gl_desc ,s.llll ,s.llll_desc ,s.o ,s.obbb ,s.obbb_desc ,s.pp ,s.ppss ,s.pprr_desc ,s.s ,s.s_desc ,@now ,@future ,1 FROM #src s WHERE NOT EXISTS ( SELECT 1 FROM dim.Account d WHERE d.is_current = 1 AND d.id <> -1 AND d.hash_key = s.hash_key AND d.hash_diff = s.hash_diff ); /*-------------------------------------------------------- Step 4. Expire current rows whose identity has dropped out of the source entirely. --------------------------------------------------------*/ UPDATE d SET effective_end_datetime = @end ,is_current = 0 FROM dim.Account d WHERE d.is_current = 1 AND d.id <> -1 AND NOT EXISTS ( SELECT 1 FROM #src s WHERE s.hash_key = d.hash_key ); COMMIT TRANSACTION; END TRY BEGIN CATCH IF @@TRANCOUNT > 0 ROLLBACK TRANSACTION; THROW; END CATCH; DROP TABLE IF EXISTS #src;END;
Full SQL Script (Including Create Table)
/*================================================================dim.Account -- Type 2 SCD Setup + Load Procedure * hash_key : identity columns (defines "same account") * hash_diff : tracked description columns (drives versioning) * filtered UNIQUE index guarantees one current row per account * #src is indexed after load * load runs inside a single transaction with rollback * expired rows end one minute before the successor starts================================================================---*//*----------------------------------------------------------------1. Table----------------------------------------------------------------*/DROP TABLE IF EXISTS dim.Account;CREATE TABLE dim.Account ( id INT IDENTITY(1,1) NOT NULL ,[4444] VARCHAR(10) NULL ,[4444_desc] VARCHAR(550) NULL ,aa VARCHAR(10) NULL ,aa_desc VARCHAR(550) NULL ,fund VARCHAR(10) NULL ,gl VARCHAR(10) NULL ,gl_desc VARCHAR(550) NULL ,llll VARCHAR(10) NULL ,llll_desc VARCHAR(550) NULL ,o VARCHAR(10) NULL ,obbb VARCHAR(10) NULL ,obbb_desc VARCHAR(550) NULL ,pp VARCHAR(10) NULL ,ppss VARCHAR(10) NULL ,pprr_desc VARCHAR(550) NULL ,s VARCHAR(10) NULL ,s_desc VARCHAR(550) NULL ,effective_start_datetime DATETIME2(7) NOT NULL ,effective_end_datetime DATETIME2(7) NOT NULL ,is_current BIT NOT NULL -- identity hash: the 10 business key columns ,hash_key AS CONVERT(VARBINARY(32), HASHBYTES('SHA2_256', CONCAT( ISNULL([4444], ''), '||' ,ISNULL(aa, ''), '||' ,ISNULL(fund, ''), '||' ,ISNULL(gl, ''), '||' ,ISNULL(llll, ''), '||' ,ISNULL(o, ''), '||' ,ISNULL(obbb, ''), '||' ,ISNULL(pp, ''), '||' ,ISNULL(ppss, ''), '||' ,ISNULL(s, '')))) PERSISTED -- change hash: the 7 tracked description columns ,hash_diff AS CONVERT(VARBINARY(32), HASHBYTES('SHA2_256', CONCAT( ISNULL([4444_desc], ''), '||' ,ISNULL(aa_desc, ''), '||' ,ISNULL(gl_desc, ''), '||' ,ISNULL(llll_desc, ''), '||' ,ISNULL(obbb_desc, ''), '||' ,ISNULL(pprr_desc, ''), '||' ,ISNULL(s_desc, '')))) PERSISTED);-- One current row per identity. Also fails the load loudly if the-- source ever produces two current versions of the same key.-- INCLUDE (hash_diff) covers the Step 3 existence check.CREATE UNIQUE INDEX UX_Account_current ON dim.Account (hash_key) INCLUDE (hash_diff) WHERE is_current = 1;/*----------------------------------------------------------------2. Default unknown row (-1)----------------------------------------------------------------*/SET IDENTITY_INSERT dim.Account ON;INSERT INTO dim.Account ( id ,[4444] ,[4444_desc] ,aa ,aa_desc ,fund ,gl ,gl_desc ,llll ,llll_desc ,o ,obbb ,obbb_desc ,pp ,ppss ,pprr_desc ,s ,s_desc ,effective_start_datetime ,effective_end_datetime ,is_current)VALUES ( -1 ,'Unknown' ,'Unknown' ,'Unknown' ,'Unknown' ,'Unknown' ,'Unknown' ,'Unknown' ,'Unknown' ,'Unknown' ,'Unknown' ,'Unknown' ,'Unknown' ,'Unknown' ,'Unknown' ,'Unknown' ,'Unknown' ,'Unknown' ,'1900-01-01' ,'9999-12-31 23:59:59.9999999' ,1);SET IDENTITY_INSERT dim.Account OFF;/*----------------------------------------------------------------3. Load procedure----------------------------------------------------------------*/CREATE OR ALTER PROCEDURE dim.usp_Load_AccountASBEGIN SET NOCOUNT ON; SET XACT_ABORT ON; DECLARE @now DATETIME2(7) = SYSDATETIME(); DECLARE @end DATETIME2(7) = DATEADD(MINUTE, -1, @now); -- expired rows end 1 min before successor starts DECLARE @future DATETIME2(7) = '9999-12-31 23:59:59.9999999'; /*------------------------------------------------------------ Step 1. Stage distinct source rows (outside the transaction to keep the write transaction short). COLLATE DATABASE_DEFAULT normalizes lakehouse collation so the hashes computed here are byte comparable with dim.Account's persisted hashes. ------------------------------------------------------------*/ DROP TABLE IF EXISTS #src; ;WITH src_cast AS ( SELECT DISTINCT CAST([4444] AS VARCHAR(10)) COLLATE DATABASE_DEFAULT AS [4444] ,CAST([4444 Desc] AS VARCHAR(550)) COLLATE DATABASE_DEFAULT AS [4444_desc] ,CAST([AA] AS VARCHAR(10)) COLLATE DATABASE_DEFAULT AS aa ,CAST([AA Desc] AS VARCHAR(550)) COLLATE DATABASE_DEFAULT AS aa_desc ,CAST([Fund] AS VARCHAR(10)) COLLATE DATABASE_DEFAULT AS fund ,CAST([GL] AS VARCHAR(10)) COLLATE DATABASE_DEFAULT AS gl ,CAST([GL Desc] AS VARCHAR(550)) COLLATE DATABASE_DEFAULT AS gl_desc ,CAST([LLLL] AS VARCHAR(10)) COLLATE DATABASE_DEFAULT AS llll ,CAST([LLLL Desc] AS VARCHAR(550)) COLLATE DATABASE_DEFAULT AS llll_desc ,CAST([O] AS VARCHAR(10)) COLLATE DATABASE_DEFAULT AS o ,CAST([OBBB] AS VARCHAR(10)) COLLATE DATABASE_DEFAULT AS obbb ,CAST([OBBB Desc] AS VARCHAR(550)) COLLATE DATABASE_DEFAULT AS obbb_desc ,CAST([PP] AS VARCHAR(10)) COLLATE DATABASE_DEFAULT AS pp ,CAST([PPSS] AS VARCHAR(10)) COLLATE DATABASE_DEFAULT AS ppss ,CAST([PPRR Desc] AS VARCHAR(550)) COLLATE DATABASE_DEFAULT AS pprr_desc ,CAST([S] AS VARCHAR(10)) COLLATE DATABASE_DEFAULT AS s ,CAST([S Desc] AS VARCHAR(550)) COLLATE DATABASE_DEFAULT AS s_desc FROM LakehouseName.dbo.[RawTable] ) SELECT [4444] ,[4444_desc] ,aa ,aa_desc ,fund ,gl ,gl_desc ,llll ,llll_desc ,o ,obbb ,obbb_desc ,pp ,ppss ,pprr_desc ,s ,s_desc -- expressions MUST match dim.Account's computed columns exactly ,CONVERT(VARBINARY(32), HASHBYTES('SHA2_256', CONCAT( ISNULL([4444], ''), '||' ,ISNULL(aa, ''), '||' ,ISNULL(fund, ''), '||' ,ISNULL(gl, ''), '||' ,ISNULL(llll, ''), '||' ,ISNULL(o, ''), '||' ,ISNULL(obbb, ''), '||' ,ISNULL(pp, ''), '||' ,ISNULL(ppss, ''), '||' ,ISNULL(s, '')))) AS hash_key ,CONVERT(VARBINARY(32), HASHBYTES('SHA2_256', CONCAT( ISNULL([4444_desc], ''), '||' ,ISNULL(aa_desc, ''), '||' ,ISNULL(gl_desc, ''), '||' ,ISNULL(llll_desc, ''), '||' ,ISNULL(obbb_desc, ''), '||' ,ISNULL(pprr_desc, ''), '||' ,ISNULL(s_desc, '')))) AS hash_diff INTO #src FROM src_cast; -- index the staged rows: read 3 times on hash_key below CREATE CLUSTERED INDEX CIX_src ON #src (hash_key); /*------------------------------------------------------------ Steps 2 to 4 mutate the dimension. Run them atomically so a failure can never leave a key with zero current rows. ------------------------------------------------------------*/ BEGIN TRY BEGIN TRANSACTION; /*-------------------------------------------------------- Step 2. Expire current rows whose identity still exists in the source but whose description set changed. --------------------------------------------------------*/ UPDATE d SET effective_end_datetime = @end ,is_current = 0 FROM dim.Account d INNER JOIN #src s ON s.hash_key = d.hash_key WHERE d.is_current = 1 AND d.id <> -1 AND s.hash_diff <> d.hash_diff; /*-------------------------------------------------------- Step 3. Insert brand new identities and new versions of the rows just expired in Step 2. A current row matching on both hashes is unchanged and skipped. --------------------------------------------------------*/ INSERT INTO dim.Account ( [4444] ,[4444_desc] ,aa ,aa_desc ,fund ,gl ,gl_desc ,llll ,llll_desc ,o ,obbb ,obbb_desc ,pp ,ppss ,pprr_desc ,s ,s_desc ,effective_start_datetime ,effective_end_datetime ,is_current ) SELECT s.[4444] ,s.[4444_desc] ,s.aa ,s.aa_desc ,s.fund ,s.gl ,s.gl_desc ,s.llll ,s.llll_desc ,s.o ,s.obbb ,s.obbb_desc ,s.pp ,s.ppss ,s.pprr_desc ,s.s ,s.s_desc ,@now ,@future ,1 FROM #src s WHERE NOT EXISTS ( SELECT 1 FROM dim.Account d WHERE d.is_current = 1 AND d.id <> -1 AND d.hash_key = s.hash_key AND d.hash_diff = s.hash_diff ); /*-------------------------------------------------------- Step 4. Expire current rows whose identity has dropped out of the source entirely. --------------------------------------------------------*/ UPDATE d SET effective_end_datetime = @end ,is_current = 0 FROM dim.Account d WHERE d.is_current = 1 AND d.id <> -1 AND NOT EXISTS ( SELECT 1 FROM #src s WHERE s.hash_key = d.hash_key ); COMMIT TRANSACTION; END TRY BEGIN CATCH IF @@TRANCOUNT > 0 ROLLBACK TRANSACTION; THROW; END CATCH; DROP TABLE IF EXISTS #src;END;
Additional Information
The post Creating a SQL Stored Procedure to Load a SCD2 appeared first on SQLServerCentral.
