Hosting an ASP.NET Core 3.1 Application With Angular to Azure Storage as a Static Website

1 Share

Last month, we had Core 3.0 available for production. SDKs for it are out, including 3.1. When used with Visual Studio 2019, there are ready-to-use templates for Angular Single Page Applications.

What if you are using this template with static content and need to host it on public a URL? Microsoft Azure Storage does provide you with the feature, "Static Website" to host an application with static content.

Read the whole story
alvinashcraft
1 hour ago
reply
West Grove, PA
Share this story
Delete

Blazor Components: The Definitive Guide

1 Share

In this guide, learn the fundamentals of Blazor Component construction and see how to build an example Blazor app that puts it all together.

In this article we’ll learn about Blazor's component model, Razor Components. Using Razor Components we'll build a component to display a weekly weather forecast. Through this process we’ll learn the fundamentals of component construction, including directives, parameters, child content/templates, routing and event handling. For simplicity we’ll use the resources given to us by the new Blazor Server app template.

Directives

Compiler directives are used to give Razor instructions that typically change the way a component is parsed or enables different functionality. Let’s create a new page to display a weekly weather forecast. In the Blazor framework pages are components which are decorated with the @page directive. The @page directive is followed by a string value which defines the component’s page route, giving it a URL which can be navigated to in the browser, ex: @page “/my-url.” Even though the @page directive enables routing, it does not remove our ability to use the component as a basic building block for other components or “pages.”

Let’s begin by adding a new Razor Component to our application called WeeklyForecast. In the project, choose the Pages folder and right click, choose Add > New Item, then select Razor Component as shown in Figure 1. Name the component WeeklyForecast.razor, then click create to finish.

Creating a new Razor Component with the Add New Item dialog.
Figure 1: Creating a new Razor Component with the Add New Item dialog.

Our component is created with a very basic boilerplate. We’ll leave this boilerplate in place and add our @page directive with the value “/weeklyforecast” to the very top of the file. It is best practice to place all directives at the top of the file unless there is a special use case where it should to be placed elsewhere. For example, the @code block is a directive which is normally located at the bottom of the component, however moving it will not cause an error.

@page "/weeklyforecast"
<h3>WeeklyForecast</h3>

@code {

}

Routing

We can run our application and view the changes in the browser. Once the app is running append /weeklyforecast to navigate to the newly-created page. The results should resemble Figure 2.

The WeeklyForecast component using the @page directive to specify routing.
Figure 2: The WeeklyForecast component using the @page directive to specify routing.

Let’s use this page to build a prototype of what our final product should look like. This will help us decide where components can be abstracted into reusable bits. We’ll display weather information to the user using HTML and CSS classes from Bootstrap and Iconic.

Inside the WeeklyForecast page, we’ll append our first prototype UI element, a day of weather forecast data. We’ll use hard coded values, which will eventually be replaced with data. The markup is contained within a div element which uses the Bootstrap card class to give it a nice appearance. Inside the card’s body, we’re using a span element with the Open Iconic classes io io-rain, which will render an icon that represents weather status.

@page "/weeklyforecast"

<h3>WeeklyForecast</h3>
<div class="card bg-light" style="width: 18rem;">
    <div class="card-body text-center">
        <span class="h1 oi oi-rain"></span>
        <h1 class="card-title">17 C&deg;</h1>
        <p class="card-text">
        Rainy weather expected Monday
       </p>
    </div>
</div>
…

We’ll save these changes and reload the WeeklyForecast page which now shows the weather card. The rendered page should look like Figure 3.

A prototype of the weekly forecast page displaying a single weather forecast.
Figure 3: A prototype of the weekly forecast page displaying a single weather forecast.

Our page is taking shape; however, we’re building a weekly forecast and we currently have a single day. Let’s modify the page so it can display five days of forecast data. Since we’ll be repeating the cards, we’ll wrap the display in a flex-box container. Since we’re using Bootstrap we can use the convenient class d-flex. Inside the d-flex container we need to repeat our weather display. We’ll rely on Razor to help us repeat the display with a foreach loop. To create a simple loop without any real data we’ll use the Enumerable.Range method to generate a sequence for us. With multiple cards being displayed, let’s remove the static width style attribute style="width: 18rem;" and let the element expand as needed. To create some whitespace between each card the m-2, or margin 2 CSS class is added.

…
<div class="d-flex">
    @foreach (var item in Enumerable.Range(1, 5))
    {
        <div class="card bg-light m-2">
            <div class="card-body text-center">
                <span class="h1 oi oi-rain"></span>
                <h1 class="card-title">17 C&deg;</h1>
                <p class="card-text">
            Rainy weather expected Monday
            </p>
            </div>
        </div>
    }
</div>
…

The result is a five-day forecast that repeats across the page as shown in Figure 4.

A prototype of the weekly forecast page displaying a single weather forecast.
Figure 4:
The weekly weather page shows a repeated weather forecast card with five static elements across the page.

By now you can probably see a pattern emerge where the individual day of weather is repeated. This repeated section could easily be a reusable component that encapsulates a day of weather. Let’s abstract our component out of the WeeklyForecast page into its own component file.

In the project’s /Shared folder we’ll create a new component called WeatherDay. We’ll remove the boilerplate content from the newly created component and move the HTML from inside of the foreach loop of the WeeklyForecast component to the WeatherDay component. This quick copy/paste job is all we need to create a basic Razor Component. With the markup moved to the WeatherDay component, we can make use of it by name in WeeklyForecast. We’ll add a WeatherDay component to body of the foreach loop.

/Shared/ WeatherDay.razor

<div class="card bg-light m-2">
    <div class="card-body text-center">
        <span class="h1 oi oi-rain"></span>
        <h1 class="card-title">17 C&deg;</h1>
        <p class="card-text">
        Rainy weather expected Monday
       </p>
    </div>
</div>

/Pages/WeeklyForecast.razor

…html
<div class="d-flex">
    @foreach (var item in Enumerable.Range(1, 5))
    {
        <WeatherDay></WeatherDay>
    }
</div>
…

When we re-run the app, it should be identical to the previous run as seen in Figure 4. There were no changes to the result as we simply moved the responsibility for rendering the card from WeeklyForecast to WeatherDay.

Parameters

Let’s replace some of the static values with component parameters. The easy way to understand component parameters in the Razor Component model is to see them as public properties that are decorated with a special [Parameter] attribute. We’ll discuss additional parameter attributes as we go, however the standard [Parameter] attribute will fit most scenarios.

Now that our component’s HTML is isolated inside the WeatherDay component we can make our component more dynamic by allowing it to accept data using parameters. For our weather component we need to show the weather summary, i.e. is it rainy, sunny, or cloudy with a corresponding icon. We’ll also display the temperature and day of the week. Let’s create a few parameters to get started and implement more detailed features as we work through each challenge. We’ll begin with an @code block, add our three properties and decorate them using the [Parameter] attribute.

@code {

    [Parameter]
    public string Summary { get; set; }

    [Parameter]
    public int TemperatureC { get; set; }

    [Parameter]
    public DayOfWeek DayOfWeek { get; set; }

}

One-Way Data Binding

To display the parameter’s value, we’ll use one-way databinding. This will simply write the value inline where the value appears in the markup. In Razor we just prefix the properties name with an @ symbol, ex: @Summary. For each parameter we’ll update the markup by replacing the static text with a data bound value. When Razor generates the final output, all values are automatically converted to a string. There is no need to manually covert a value like TemperatureC even though it is an int, however we do have the option of customizing the formatting if we wish.

<div class="card bg-light m-2">
    <div class="card-body text-center">
        <span class="h1 oi oi-rain"></span>
        <h1 class="card-title">@TemperatureC C&deg;</h1>
        <p class="card-text">
        @Summary weather expected @DayOfWeek
     </p>
    </div>
</div>

Now that our component has parameters that are data bound, we can return to the WeeklyForecast page and update our component instance to make use of the new feature. We’ll locate the WeatherDay component on the page and set some static values for our parameters.

@foreach (var item in Enumerable.Range(1, 5))
{
    <WeatherDay
        TemperatureC="20"
        Summary="Cloudy"
        DayOfWeek="DayOfWeek.Friday">
    </WeatherDay>
}

Let’s continue by adding some dynamic data to our WeeklyForecast page. We’ll inject a WeatherForecastService on the page and use it to generate data. The WeatherForecastService is included in the new project template and is located under the /Data folder in the project. Open the WeatherForecastService.cs file and examine how it works. We can see there is a collection of Summaries that are used to fill the Summary property. The method, GetForecastAsync, generates 5 random WeatherForecast values based on a start date.

Let’s simplify the Summaries list to only include the values: Cloudy, Rainy and Sunny. This will correspond to three icons available in our project.

private static readonly string[] Summaries = new[]
{
 //"Freezing", "Bracing", "Chilly", "Cool", "Mild",
 //"Warm", "Balmy", "Hot", "Sweltering", "Scorching"
 "Cloudy", "Rainy", "Sunny"
};

In WeatherDay we’ll use a read-only property to determine which icon to show based on the Summary field. A quick ternary statement converts the Summary string to the corresponding icon name.

string IconCssClass =>
        Summary == "Cloudy" ? "cloud" :
        Summary == "Rainy" ? "rain" :
        "sun";

Now we can use the IconCssClass property to modify the CSS value of the component’s icon.

<span class="h1 oi oi-@IconCssClass"></span>

Injecting a Service

The WeatherDay component can now be bound to dynamic data. We’ll inject the WeatherForecastService on the page using the @inject directive. The dependency is available because the WeatherForecastService was already registered in Startup.cs by the template. We can see how dependency injection (DI) is configured by looking in the ConfigureServices method.

services.AddSingleton<WeatherForecastService>();

On the WeeklyForecast page, beneath the @page directive we add @inject and specify both the Type (T) that will be resolved and the variable name an instance of that type will be assigned, ex: @inject T myTInstance. An @using directive will bring the WeatherForecastService into scope.

@page "/weeklyforecast"
@using Data;
@inject WeatherForecastService WeatherService

OnInitializedAsync Lifecycle Method

With the WeatherForecastService available we can now call the GetForecastAsync method which generates an array of WeatherForecast objects. The data should be loaded when the component is first initialized. Razor Components handle initialization through the OnInitializedAsync and OnInitialized lifecycle methods. The component lifecycle methods are automatically inherited from the ComponentBase class that makes up all Razor Components.

It’s best practice to use asynchronous code whenever possible as it leads to an overall better user experience. In addition, our WeatherForecastService provides async functionality, so we’ll be using OnInitializedAsync to fetch data as the component initializes.

Let’s add a field to capture the data that will be displayed on the page. We’ll create an empty array of WeatherForecast called forecasts. Following the forecasts field, we’ll override the OnInitializedAsync method and populate the forecast field by awaiting the call to GetForecastAsync.

WeatherForecast[] forecasts;

protected override async Task OnInitializedAsync()
{
    forecasts = await WeatherService
                .GetForecastAsync(DateTime.Now);
}

Now that we’re using data from our WeatherService we’ll need to replace the static loop in our view with one that uses the forecasts array. Inside the new loop we reference the current item and apply the corresponding property value to the parameter of the component. The .NET compiler is smart, so we’ll only need to use the @ symbol on string values to identify string literals from property values.

@*foreach (var item in Enumerable.Range(1, 5))*@
@foreach (var forecast in forecasts)
{
     <WeatherDay
         TemperatureC="forecast.TemperatureC"
         Summary="@forecast.Summary"
         DayOfWeek="forecast.Date.DayOfWeek">
     </WeatherDay>
}

Since we’re no longer working with static data, we should consider the possibility of null values. Currently if the component renders while the forecasts array is null, a NullReferenceException will be thrown when entering the foreach loop. To safeguard against this, we use an if/then statement to provide a display when no data is present.

@if (forecasts == null)
{
    <span>No Data</span>
}
else
{
    foreach (var forecast in forecasts)
    {
        <WeatherDay TemperatureC="forecast.TemperatureC"
         Summary="@forecast.Summary"
        DayOfWeek="forecast.Date.DayOfWeek">
        </WeatherDay>
    }
}

We can now render data dynamically by visiting the weeklyforecast route as shown in Figure 5.

The weekly weather page shows a repeated weather forecast card with five static elements across the page.
Figure 5: The weekly weather page shows a repeated weather forecast card with five static elements across the page.

Our WeeklyForecast and WeatherDay components are starting to come together. We’re able to dynamically populate components based on a collection of data which is loaded as the component initializes. The data flows from the WeeklyForecast directly to each WeatherDay component through one-way data binding. This is a common way of displaying data and works well when we have a consistent UI we’re creating.

Let’s expand on our WeatherDay component and allow its UI to be extended further by providing a template region.

Child Content/Templates

Templated components are components that accept one or more UI templates as parameters. Templates can be used customize a portion of the components rendered output. We’ll continue with our WeatherDay component as an example of how to implement a template.

To make our WeatherDay component more flexible we’ll be adding a template region shown as a red block in Figure 6. This area will allow developers to insert any HTML, Razor, or Component as child content.

A red box outlines where the template region of the component will be created.
Figure 6:
A red box outlines where the template region of the component will be created.

To add a template to our WeatherDay component we’ll make use of the RenderFragment class. A RenderFragment represents a segment of UI content, implemented as a delegate that writes the content to a RenderTreeBuilder (the Blazor virtual DOM). On the surface one might assume the child content is written as raw HTML, however the RenderFragment conforms to the component architecture of Blazor.

On the surface one might assume the child content is written as raw HTML, however the RenderFragment conforms to the component architecture of Blazor.

Let’s add a RenderFragment to our WeatherDay component. The RenderFragment is added exactly like any other component parameter using a property and [Parameter] attribute. For this example, we’ll call the property CustomMessage.

@code {

    [Parameter]
    public RenderFragment CustomMessage { get; set; }

    [Parameter]
    public string Summary { get; set; }
…

}

To make use of the parameter, we reference the RenderFragment when we would like it to appear in our component markup. In between the h1 and p elements of our component the @CustomMessage is placed, this is where the template will be rendered.

<div class="card bg-light m-2">
    <div class="card-body text-center">
        <span class="h1 oi oi-@IconCssClass"></span>
        <h1 class="card-title">@TemperatureC C&deg;</h1>
        @CustomMessage
        <p class="card-text">
        @Summary weather expected @DayOfWeek</p>
    </div>
</div>

When using the WeatherDay component the template is applied by specifying the template by name using an HTML tag. Inside this tag we can use Razor markup, HTML, other components, or any combination of these things. Let’s apply this to our example by adding a simple if statement to check for a Rainy forecast and then display a special alert on those items. Inside the CustomMessage we’ll add some Razor code and basic element styled with a Bootstrap alert alert-danger CSS class.

<WeatherDay TemperatureC="forecast.TemperatureC"
        Summary="@forecast.Summary"
        DayOfWeek="forecast.Date.DayOfWeek">
    <CustomMessage>
        @if (forecast.Summary == "Rainy")
        {
            <div class="alert alert-danger">
                Tornado Warning!
            </div>
        }
    </CustomMessage>
</WeatherDay>

When we run the application and view the weekyforecast page, it now displays a “Tornado Warning!” alert box inside of the WeatherDay component as seen in Figure 7.

The weekly forecast is rendered with a Tornado warning displayed in the template region of the WeatherDay component.
Figure 7: The weekly forecast is rendered with a Tornado warning displayed in the template region of the WeatherDay component.

Thus far, the WeeklyForecast and WeatherDay components have most of the features we commonly find in component architecture. However, one important aspect of UI development hasn’t been discussed yet, interactivity. Next, we’ll look at how to handle events with Blazor by giving users the ability to select an item shown in the weekly forecast.

Event Handling

When we think about events and delegates in C#, it’s likely that we’ll consider the: event and delegate keywords, or the Action and Func delegate-types. These are technically valid options when working with standard C# assemblies. Working with the UI in a Blazor application using Razor Components introduces a different architecture pattern and a special delegate called the EventCallback.

The EventCallback is a delegate-type used to expose events across components. A parent component can assign a callback method to a child component's EventCallback. When using the EventCallback in this manner, the parent and child components are automatically re-rendered when events are raised. Using event, delegate, Action, or Func, may result in the UI not updating as expected. For this reason, the EventCallback should always be used in Razor Components.

The EventCallback is a delegate-type used to expose events across components.

To demonstrate how EventCallback is used, we’ll continue with the WeeklyForecast and WeatherDay components. We’ll add the ability for a WeatherDay to be selected from the weekly forecast when the user clicks on a given day.

We’ll begin by adding a new parameter to our WeatherDay component named OnSelected. The OnSelected parameter should be an EventCallback of DayOfWeek. This means the event will return a type of DayOfWeek as an argument. The DayOfWeek is a value we can use to identify which item triggered OnSelected.

[Parameter]
public EventCallback<DayOfWeek> OnSelected { get; set; }

Beneath the OnSelected parameter an event handler is created, and this handler is responsible for raising the OnSelected event delegate on the parent component. To invoke OnSelected we call InvokeAsync and pass the current DayOfWeek as an argument.

void HandleOnSelected()
{
    OnSelected.InvokeAsync(this.DayOfWeek);
}

Continuing with the WeatherDay logic, a Selected property is added to indicate if the component is in a selected state. We’ll use this property not only to bind the selected value to the component, but to also set the corresponding CSS for the UI. Using a private property SelectedCss we determine which CSS class to apply based on the value of the Selected property. If the item is selected, the bg-primary text-white class is used to highlight the component and invert the text color, otherwise the value will default to bg-light.

[Parameter]
public bool Selected { get; set; }

private string SelectedCss => Selected ?
        "bg-primary text-white" : "bg-light";

In our component markup we can now trigger the HandleOnSelected event delegate when the user clicks the UI. On the outermost div element we’ll attach an onclick event handler and assign it to the HandleOnSelected method. We’ll also modify the div to use the SelectedCss value, effectively toggling the UI’s appearance.

<div class="card m-2 @SelectedCss"
        @onclick="HandleOnSelected">
    <div class="card-body text-center">
        …
    </div>
</div>

The WeatherDay component can now be selected and we can apply the new feature with a few modifications to the WeatherForecast class and WeeklyForecast component. Since the WeatherForecast provides the data and state for our view, we’ll add a Selected property which we can then bind to our components.

public class WeatherForecast
{
    public bool Selected { get; set; }
     …

In the WeeklyForecast component an event handler is added for the OnSelected event. The method HandleItemSelected will accept the argument DayOfWeek which we can then use to set identify which item was selected. In the method a quick loop over each forecast is used to clear the selected value. Once cleared we can use a LINQ statement to find the matching DayOfWeek and toggle set the selected value to true.

void HandleItemSelected(DayOfWeek selectedValue)
{
    // Clear selections
    foreach (var item in forecasts)
        item.Selected = false;

    forecasts.First(f =>
    f.Date.DayOfWeek == selectedValue).Selected = true;
}

In the WeeklyForecast the markup receives a few updates to tie everything together. Where the WeatherDay component is used, the new properties are applied. The OnSelected method is given the HandleItemSelected delegate and the Selected value is bound to the forecast item’s Selected property.

<WeatherDay TemperatureC="forecast.TemperatureC"
            Summary="@forecast.Summary"
            DayOfWeek="forecast.Date.DayOfWeek"
            OnSelected="HandleItemSelected"
            Selected="forecast.Selected">

With the updates complete we can now run the application and navigate to the weeklyforecast page and select items from the view as shown in Figure 8.

The second item in the list is selected when clicked by the user.
Figure 8: The second item in the list is selected when clicked by the user.

We could explain this concept further by adding any custom logic to the HandleItemSelected method. Imagine what features you might add when selecting an item. Some examples include: displaying the hourly weather forecast, listing closed businesses or suggesting activities for the given forecast. This concept can be applied to many business applications where data includes parent-child relationships.

Conclusion

Throughout this article we learned the fundamentals of component construction, including directives, parameters, child content/templates, routing and event handling. Each example guided us through the process of creating a component while introducing topics necessary for understanding the Blazor architecture. The intention of this article was to provide information that will immediately make us productive when using the Blazor framework.

Read the whole story
alvinashcraft
1 hour ago
reply
West Grove, PA
Share this story
Delete

"Can I… in the new Edge?"

1 Share

This post is intended to collect a random set of Questions I’ve been asked multiple times about the new Edge. I’ll add to it over time. I wouldn’t call this a FAQ because these questions, while repeated, are not frequently asked.

Can I block my employees from accessing the edge://flags page?

You can add “edge://flags” to the URLBlocklist if desired. Generally, we don’t recommend using this policy to block edge://* pages as doing so could have unexpected consequences.

Note that, even if you block access to edge://flags, a user is still able to modify the JSON data storage file backing that page: %LocalAppData%\Microsoft\Edge\User Data\Local State using Notepad or any other text editor.

Similarly, a user might specify command line arguments when launching msedge.exe to change a wide variety of settings.

Can I disable certain ciphers, like 3DES, in the new Edge?

The new Edge does not use SChannel, so none the prior SChannel cipher configuration policies or settings have any effect on the new Edge.

Group Policy may be used to configure the new Edge’s SSLVersionMin (which does impact available cipher suites, but doesn’t disable all of the ciphers considered “Weak” by SSLLabs.com’s test).

Chromium explicitly made a design/philosophical choice (see this and this) not to support disabling individual cipher suites via policy. Ciphersuites in the new Edge may be disabled using a command-line flag:

msedge.exe –cipher-suite-denylist=0x000a https://ssllabs.com

A few other notes:

  • The cipher suite in use is selected by the server from the list offered by the client. So if an organization is worried about ciphers used within their organization, they can simply direct their servers to only negotiate cipher suites acceptable to them.
  • The Chrome team has begun experimenting with disabling some weaker/older ciphersuites; see https://crbug.com/658905
  • If an Enterprise has configured IE Mode, the IE Mode tab’s HTTPS implementation is still controlled by Internet Explorer / Windows / SChannel policy, not the new Edge Chromium policies.



Read the whole story
alvinashcraft
2 hours ago
reply
West Grove, PA
Share this story
Delete

Adobe Sign: Implementing Microsoft SharePoint Automation

1 Share

One of my favorite new features, available now in our Adobe Sign plugin for SharePoint, is what we call “Web Form Mappings.” This feature gives you the ability to create a web form (what in Adobe Sign parlance used to be called a widget), which is a “self-serve,” sign-enabled agreement, then use that as an entry point for internal or external customers. This will feed the data from that form they fill out and sign quickly, easily, and directly into SharePoint. You also, of course, can get a copy of that agreement automatically uploaded to your SharePoint site for central visibility and management.

This is a great time saver in many situations. Think about all the forms that need to be filled out and signed:

  • HR (too many forms to list)
  • Pre-qualifying forms for a purchase
  • Forms to obtain physical access to facilities
  • Release of liability forms
  • Consent forms for data collection

This list could go and on and on. In many of these cases, this may be the ‘first impression’ that your customers or potential employees get of how you do business. I think it’s always best to find ways to make these experiences seamless, quick, easy, and as painless as possible for everyone. This is one pretty simple way to achieve this for processes where it makes sense. Here’s how we make this happen.

1. Create your “web form”

To start off you will need to create a “web form” in your Adobe Sign account. To make your life easier for configuration and possible troubleshooting later if things don’t quite go as planned, you should make sure your field names contain no spaces. While this is not required for this process to work, I find this best practice to be a good habit to get into. It will also help if you fill out and sign the web form one time, as this step will be needed before we can map the data from the form into SharePoint list fields.

For this tutorial, I’ve created a web form that looks like this:

Screen-shot of example fields in web-form. Your fields may vary depending on your use case.

Once you have your web form prepared (a gentle reminder), you should fill it out and sign it at least one time using example data.

Make sure you already have the plugin installed and configured in your SharePoint site. Either the tenant or site level installation are fine and will allow for this process to work.

2. Create the list to hold the data

Create a “custom list” in SharePoint and add all the columns that you’ll need to map the data from the fields in your web form. My columns look like this:

Screen-shot of columns in SharePoint corresponding to fields on web-form.
Description field is multi-line “plain text” in my list.

3. Map the data from the “web form” to the SharePoint list

Next, you’ll need to go into the configuration for the SharePoint plugin and find the area for “Web Form Mappings.”

Go to Site contents and click the Adobe Sign item in the list:

Shows site-contents and the Adobe Sign item to click.
Select the “Adobe Sign” item in the list.

Once this opens, find and select the “Web Form Mappings”:

Image of config page with indicator on Web Form Mappings item to click
Click on “Web Form Mappings.”

This will open to a page that looks something like this:

Web Form Mapping config page list
The Web Form Mappings list.

In the page displayed, you will see any Web Forms available to the user logged into SharePoint as list items. If the column “LIST” is blank, it means that this web form has not yet been associated to a list in SharePoint. To begin the mapping process, just click the ‘+’ symbol next to the list to start mapping the fields and you should get an interface similar to the below. Select your list from the drop-down, select the web-form field and then the SharePoint column, and click “Add Rule.”

Mapping interface process.

Repeat this process for all the fields you’d like to “Map” into SharePoint columns. Once you have finished this you should have something like this:

Shows 9 mapping rules as seen in the interface on the SharePoint config page
Mapping Rules configured.

Click the “Save” button at the bottom and make sure to turn on the toggle for saving a copy of the signed web-form to SharePoint. Your list item should now be configured similar to this:

Saved list item.

Now the fun part … go test it! (⌐■_■)

Here is a screenshot of my example web form being filled:

Filled web-form.

And now showing the data captured into SharePoint:

Captured data in SharePoint.

There’s also a copy of the signed agreement and the “audit trail” in the configured location on my SharePoint site.

More detailed info on setting up this process can be found on our Adobe Sign HelpX.

I think you’ll be able to find many use cases for this type of process.

Happy Adobe Signing!!


Adobe Sign: Implementing Microsoft SharePoint Automation was originally published in Adobe Tech Blog on Medium, where people are continuing the conversation by highlighting and responding to this story.

Read the whole story
alvinashcraft
2 hours ago
reply
West Grove, PA
Share this story
Delete

Code Smell: Abstractions?

1 Share

I recently read a great blog article by Coding Unicorn over on dev.to titled “Flexible code considered harmful”. Forgiving the over-used “considered harmful” title, the article was extremely thought-provoking. It’s fairly short and I recommend you give it a read.

She makes an interesting point about how creating flexible code means that the code could be easily extended in the future, but those extension points have a cost in increased complexity. This means that the code is actually harder to understand and harder to change.

She also mentions the “Use/Reuse Paradox” (another good read, if a bit abstract) which indicates that things that are easy to use are difficult to reuse.

Her summary point is “flexible and abstract code is hard to use and also hard to understand”. This point is certainly worth consideration. As we make code more flexible and abstract, does it become harder to use and understand?

Let’s analyze this with some sample code.

Let’s use an application that organizes and displays articles. Here is the structure for a sample article (highly simplified):

As indicated, each article can be tagged with one or more tags. In our interface, if we select one tag, we want to filter a list of articles by that tag. But we want to be able to drill down as well. For example, after selecting all javascript articles, we may want to drill down to just those related to Express. So once we select a tag and filter the articles to just those with that tag, we need to create a list of tags that all of those articles contain. We will need to make sure this list is de-duplicated, and we also need to remove the selected tag from the list.

Be sure you understand what the requirements of our task are before you try to read the code. Now let’s create an algorithm to do this given a list of articles and a selected tag:

To understand anything unfamiliar in the above code, see the notes for the algorithm here.

I wrote this algorithm very straightforwardly. I tried to make it simply do the work. I added no abstractions. I would consider this the quickest way to get it working. It does the job, and the code is perhaps “simple” since it uses little to no abstractions. Does that make it easy to use? Certainly calling the function is easy to do.

But what if we applied some typical coding refactorings and introduced some abstractions?

Exercise: For a fun exercise, try taking this algorithm and “fixing” it before you look at my adjusted solution. Just make it better and more readable according to your own judgments. You can click this link and make your changes. Then compare to what I did with my fix shown below and see if you arrived at a similar solution.

And now here’s the refactored algorithm, adding what I considered to be appropriate abstractions:

Look at what has happened. I’ve created some sub-functions and a single class TagList, and now I’ve got all these reusable pieces that could be composed to do other jobs. Most of these functions can easily be reused. The TagList could be used in a lot of other places doing other jobs with tags in an application like this.

I’ve added abstractions. I’ve arguably made the code more extensible and reusable. Have I made it more difficult to use or understand? You’d have a very hard time convincing me that the original solution was better in any way.

Would you say that this code is more readable than the original algorithm? Although readability can be subjective, I would guess that most people would say the new algorithm is more readable.

One important point about abstractions that is critical to understand is that an abstraction is basically a way to handle several smaller pieces together with a simpler, single “handle.” A good example of an abstraction is a steering wheel in a car. It’s a simple tool that actually controls a very complex mechanism of rods and gears and various pieces. When we abstract away some of our code we give ourselves a simpler way to work with and reason about that code. That reduces our cognitive load. In this fantastic article on programming and cognitive load, you can read about how cognitive load is essentially our hard limit as programmers. Abstractions allow us to work better and faster.

Of course, like all things, this can be taken to an extreme. We generally call this over-engineering or the YAGNI principle.

So, by adding these abstractions, did I over-engineer the solution? Was adding a “TagList” class too much? I tried implementing the algorithm without that class and I honestly felt like it made the code simpler. Another fun exercise: take my final algorithm and try to refactor it and remove the TagList. After you do ask yourself if you think the code is now easier to use?

One final point to explore is that we have used a rather simple code here. In a production system, the complexity is often multiplied by a factor of 10 or more. So does this hold up in a more complex system? We would have to spend hours (or perhaps weeks or months) together working on a system to really answer that question fully, but for reference, I actually based this example on a more complex algorithm that did the same thing in a production application I built. In that application, I implemented the full algorithm and even with abstractions I had a very difficult time keeping the cognitive load light enough to arrive at a correct solution. Without the abstractions, I would never have been able to create a working solution.

So yes, we can over-engineer things, but avoiding abstractions is unlikely to make our code easier to write or read or extend.

Agree? Disagree? Signup for my newsletter here.

Happy Coding

Visit Us: thinkster.io | Facebook: @gothinkster | Twitter: @GoThinkster


Code Smell: Abstractions? was originally published in Thinkster.io on Medium, where people are continuing the conversation by highlighting and responding to this story.

Read the whole story
alvinashcraft
3 hours ago
reply
West Grove, PA
Share this story
Delete

Microsoft’s New Cloud Printing Service Moves Closer to Release

1 Share
Microsoft 365 Microsoft 365

Early last year, we first caught wind that Microsoft was working on a new cloud-based printing feature. The idea is simple, bring printing into the modern age with a cloud-based printing solution.

Anyone who has spent more than five minutes trying to configure a network printer knows the frustration when things don’t go according to plan. Microsoft is looking to make this process easier with a new service coming to Microsoft 365.

Now in private preview, Universal Print, spotted by Walking Cat, is a Microsoft 365 cloud-based print infrastructure that will make it easier to deploy secure print experiences for Enterprise and Education customers. To be able to use the feature, you will need an Azure Active Directory tenant and Windows 10 1903 or later; Microsoft says that the service does not require Windows Server.

Based on the prompt to register for the preview, it looks like this may be a feature of Microsoft 365 and that the preview will launch in the next couple of weeks. That being said, this was not publicly announced and timelines can and will likely shift.

The service will allow the print administrator to register their printers with Azure Active Directory and then the admin can manage the service from a central location; you will not need to deploy a print server. Once registered, a user can then discover printers using their Azure Active Directory credentials that are shared with their account.

While this may not be a groundbreaking new feature for Microsoft and its customers, it is one that will help out with one of the most frustrating parts of setting up a user; printing. Hopefully, this feature will be announced in the near future but for now, we need to wait a little bit longer.

The post Microsoft’s New Cloud Printing Service Moves Closer to Release appeared first on Petri.

Read the whole story
alvinashcraft
3 hours ago
reply
West Grove, PA
Share this story
Delete
Next Page of Stories
