Agents feel continuous only when they can operate across two very different time horizons. They need the recent turns that make the current conversation coherent, and they need a smaller set of durable facts that can follow an authenticated user into a new conversation.
This sample implements both horizons on Azure App Service with Microsoft Agent Framework, Azure Managed Redis, Azure Cosmos DB for NoSQL vector search, and Azure OpenAI. It is deployed and available as a complete reference implementation with a browser UI, deterministic local mode, tests, Bicep, and Azure Developer CLI support.
Sample: github.com/seligj95/app-service-agent-memory
Why one memory store is not enough
Conversation history is ordered, session-specific, frequently updated, and naturally short-lived. The agent needs it to resolve statements such as “use the second option” or “what did I just say?”
Durable memory is selective, user-scoped, and useful across sessions. It holds facts such as a preferred deployment region, product name, accessibility need, or writing preference. Retrieval is semantic rather than chronological.
Putting both into one unbounded prompt makes cost, latency, privacy, and deletion harder to reason about. The sample instead gives each horizon a purpose-built store and joins them through the Agent Framework context pipeline.
The Azure architecture
The public FastAPI application runs on one always-on App Service Premium v4 instance with Python 3.13. The browser creates demo user and conversation IDs in local storage. That keeps the sample easy to explore, but it is not production authentication.
For every chat turn, the application:
- Validates the user ID, session ID, message, and retrieval limit.
- Loads bounded conversation history from Azure Managed Redis.
- Creates an embedding for the new input.
- Runs a partition-scoped vector query in Cosmos DB for the same user.
- Adds relevant durable memories to the Agent Framework context.
- Runs
gpt-5-mini. - Stores the new conversation messages in Redis and refreshes their TTL.
- Extracts conservative durable facts, embeds them, deduplicates them, and upserts them to Cosmos DB.
The chat response also returns memory attribution so the UI can show that a memory influenced the turn.
Short-term history with a custom HistoryProvider
Agent Framework's current Python API makes history a context provider. The custom provider only implements the storage boundary; the framework handles when to load and persist messages.
class RedisHistoryProvider(HistoryProvider):
def __init__(self, store, ttl_seconds, max_messages=40):
super().__init__("redis-history")
self._store = store
self._ttl_seconds = ttl_seconds
self._max_messages = max_messages
async def get_messages(self, session_id, *, state=None, **kwargs):
user_id = _required_state_value(state, "user_id")
values = await self._store.load(user_id, session_id)
return [Message.from_dict(json.loads(value))
for value in values[-self._max_messages:]]
async def save_messages(self, session_id, messages, *, state=None, **kwargs):
user_id = _required_state_value(state, "user_id")
values = [json.dumps(message.to_dict()) for message in messages]
await self._store.append(
user_id, session_id, values, self._ttl_seconds, self._max_messages
)The Redis key is session:{user_id}:{session_id}. Each append also trims the list and refreshes the seven-day TTL. Serializing the complete Agent Framework Message preserves tool and attribution metadata instead of reducing history to plain strings.
Durable recall with a custom ContextProvider
The durable provider participates before and after the model call.
class CosmosContextProvider(ContextProvider):
async def before_run(self, *, agent, session, context, state):
user_id = _required_state_value(state, "user_id")
embedding = await self._embeddings.embed(_latest_input_text(context))
recalled = await self._store.recall(
user_id, embedding, self._recall_limit
)
state["recalled_memories"] = [
item.model_dump(mode="json") for item in recalled
]
if recalled:
facts = "\n".join(f"- {item.text}" for item in recalled)
context.extend_instructions(
self.source_id,
"Use these durable memories only when relevant:\n" + facts,
)
async def after_run(self, *, agent, session, context, state):
for fact, category in extract_durable_facts(_latest_input_text(context)):
embedding = await self._embeddings.embed(fact)
await self._store.remember(
state["user_id"],
fact,
category,
state["source_turn"],
embedding,
)The Cosmos container uses /user_id as its partition key and a 1,536-dimension cosine quantizedFlat vector index. Recall is always routed to one user's partition and is bounded to a small result set. A stable ID derived from the user scope and normalized content hash makes writes idempotent.
Passwordless by default
App Service uses its system-assigned managed identity for every data service.
- Azure OpenAI: Cognitive Services OpenAI User
- Cosmos DB: native built-in data contributor
- Key Vault: Key Vault Secrets User
- Azure Managed Redis: database-scoped Entra access-policy assignment
Azure OpenAI and Cosmos DB local authentication are disabled. Redis requires TLS and Entra authentication, and its access keys are disabled. The application explicitly selects ManagedIdentityCredential in Azure and AzureCliCredential for local real-service development. It does not use a broad production credential chain.
Key Vault remains the secrets boundary for future extensions, although this passwordless sample does not need a runtime secret.
Try it locally without Azure
The deterministic fake mode exercises the real provider pipeline and complete UI without an Azure subscription:
uv sync --python 3.13 --all-groups
uv run uvicorn app.main:app --reloadOpen http://127.0.0.1:8000, tell the agent “My favorite launch color is teal,” start a new conversation, and ask for the color. You can inspect attribution, list the stored memory, and forget it.
Deploy with Azure Developer CLI
After creating an azd environment and setting its subscription and supported region, deployment is one command:
azd up --no-promptThe Bicep creates App Service, Managed Redis, Cosmos DB, Azure OpenAI model deployments, Key Vault, Application Insights, and Log Analytics. A smoke test then checks health, same-session history, explicit remember, new-session recall, list, forget, and absence after forget.
Azure Managed Redis availability is subscription- and region-dependent. The deployed reference uses East US 2 after the service preflight rejected East US for this subscription.
What the demo deliberately does not hide
The browser identity is anonymous and user-controlled. That is useful for understanding the data flow, but a production application must replace it with authenticated claims and authorization on every memory operation.
The sample also keeps one App Service instance. Before scaling out, replace the in-process conversation lock with a distributed lock so concurrent requests cannot reorder one session's history.
Other production work includes private endpoints and VNet integration, consent and retention policy, user export and deletion, content safety, prompt-injection defenses, abuse throttling, per-user quotas, and evaluation of retrieval thresholds.
Learn more
- Microsoft Agent Framework memory
- Agent Framework context providers
- Configure Python on Azure App Service
- Use Microsoft Entra ID with Azure Managed Redis
- Vector search in Azure Cosmos DB for NoSQL
- Use Azure OpenAI without keys
Two memory horizons make the agent easier to operate and easier to trust: session history remains temporary, durable memory remains selective and user-scoped, and both have explicit lifecycle controls.
